AC Miniature Circuit Breaker, 120V/240V 2 Pole 32 Amp DIN Rail Mount Circuit Breaker, MCB C32 Solar AC Disconnect Switch,Thermal Magnetic Trip

DIN rail mount AC miniature circuit breaker (MCB) for overload and short-circuit protection in solar AC systems, RVs and household circuits.

• Function: Protects 110V/120V/220V/230V AC circuits from overload and short-circuit damage; also suitable for control and isolation.
• Curve C Trip Characteristic: Magnetic trip range of 5–10× rated current.
• Quality Build: Silver alloy contacts, flame-retardant housing, and color-coded indicator window (green = off, red = active) to prevent misoperation.
• Built-In DIN Rail: Includes a 35mm DIN rail for hassle-free installation — no extra purchase needed.
• Easy Installation: Hook the top slot onto the rail and press the bottom firmly into place; screw terminal connections included.

Brand: Cnjiapei  |  Rated Voltage: AC 120V/240V  |  Poles: 2P  |  Breaking Capacity: 6kA  |  Standard: IEC60898-1  |  Operating Temp: -25°C to +60°C

Package Includes: 1× AC miniature circuit breaker, 1× 35mm DIN rail, 2× screws.
