Project Profile: 300 m² Ground-Mounted Solar PV System (Netherlands)

1. Project Overview

  • Project Name: 300 m² Ground-Mounted Distributed PV System

  • Location: Netherlands

  • Land Area: Approx. $300\text{ m}^2$ (Total site area)

  • Application: C&I Open Land / Agricultural Idle Land / Standalone Ground Solar Plant

  • Operational Mode: Self-Consumption with Grid Export (On-Grid / Hybrid System)

2. System Specifications

  • PV Module Spec: 620W High-Efficiency N-Type TOPCon Monocrystalline Modules (Bifacial optional)

    • Dimensions: Approx. $2382 \times 1134 \times 30\text{ mm}$ ($\sim 2.7\text{ m}^2/\text{module}$)

    • Module Efficiency: $\ge 22.8\%$

  • Module Quantity: Approx. 70 - 80 units (Accounting for optimal tilt angle, row spacing, and maintenance access)

  • Total Capacity: $43 - 50\text{ kWp}$ ($\sim 49.6\text{ kWp}$ based on 80 units)

  • Inverter System: High-current 3-Phase String / Hybrid Inverter (IP65/IP66 outdoor rating, fully compatible with $15\text{A}+$ MPPT input)

  • Mounting System: AL6005-T5 High-Strength Anodized Aluminum / Hot-Dipped Galvanized Steel with Ground Screws or Concrete Foundation. Fully compliant with Eurocode & Dutch NEN 7250 standards for wind and snow loads.

3. Estimated Yield & Environmental Impact

  • Annual Peak Sun Hours: Approx. $1,000 - 1,050\text{ h/year}$ (Optimized yield via optimal ground tilt)

  • Estimated Annual Generation: $\sim 50,000 - 52,000\text{ kWh}$

  • Carbon Offset & ESG Benefits:

    • $\text{CO}_2$ Reduction: Approx. $20 - 22\text{ metric tons/year}$

    • Tree Equivalent: Equivalent to planting $\sim 1,100\text{ trees}$ annually

  • Economic Value: Drastically lowers localized energy costs and generates revenue via grid feed-in under local Dutch renewable energy schemes (e.g., SDE++).

4. Key Project Highlights

  1. Optimized Angle & Bifacial Gain: Ground mounting allows precision adjustment for optimal tilt and azimuth angles. Combining 620W N-type bifacial modules enables additional power generation from rear-side reflections.

  2. Rapid Installation & High Corrosion Resistance: Built on ground-screw foundations and anodized AL6005-T5 structures, ensuring minimal soil disruption, fast assembly, and superior resistance to Netherlands' humid weather.

  3. Full European Standard Compliance: Engineered in strict accordance with NEN 1010 and NEN 7250 regulations with full CE & TÜV certifications.
